X4-7405/X4-7408
X4-7405/X4-7408 Information
Key Features
> Dual Staggered Print Heads
With Dual staggered print heads and an
Industrial design, the printer delivers
quality prints with high speed, satisfying high volume
customer requirements.
> Fiber optic transition system
A 1.25G/s data processing capacity, maintains a
fluent data feed for high resolution image prints.
The fiber optic system benefits from an anti Interference
ability, maintaining stability during high speed output.
> VSDT Printing Technology
YILIJET’s original VSDT technology
delivers ultra high quality prints with drop dots from 2.5pl
2880DPI to 27pl
> Heating & Cooling system
To maintain a high speed and stable output, the X4 series printer was designed with a multi-heating and cooling
system, all components of the heating system are independently controlled.
The infrared heating control system has intelligent switching according to Printing Status.
Technical Specification
Printing Technology- Print Head On demand Piezoelectric (2 Staggered Print Heads)-
Number of Print Heads- 2
Productivity
Express Mode- 65sqm/h
Production- 44sqm/h
Quality- 34sqm/h
Fine Art-24sqm/h
Resolution & Software
Resolution- 1440dpi (Max)
Software- Sai Photprint
Media
Media Width Maximum- 1920mm
Roll Dimension & Weight Maximum- 210mm 40Kg
Print Width-1880mm in one Roll - 2 Rolls 914mm
Feeding & Take-Up System- Auto-Feeding & Take-Up System with Dual Roll Printing Support
Ink System
Ink Type- Eco-Solvent (DX5) Water Based / Sublimation(5113)
Ink Supply System- 1.5L - Bulk System with Automatic supply
Ink Colours- CMYK
Ink Curing System- Integrated Tri-Heating System, extended infrared heating and cooling.
Dimensions & Weight
Machine- LxWxH 3260×930×1800mm
Operational Requirements
Connectivity- High Speed USB 3.0
Power- Single Phase, 220VAC±10%, 50/60Hz; 600W (Machine),900W(Heater)
Environment- Temp. 15~30°C; RH 40~60%
Warranty 1 Year Warranty Standard
*Specifications above are subject to change without notice
