YOTTA YD-F2513R4-35

YOTTA YD-F2513R4-35 Information

Key Features

> Secondary Head Carriage

The F2513-35R4 utilizes a secondary Print Head carriage to allow the Print Head to Print on to objects up to 340mm

> Automatic Height Measurement System

Media height can be set automatically via software control.

> Anti-Collision Device

The Print Carriage is fitted with an Anti-Collision device to protect the Print Head & Operator in the case of obstruction.

> Negative Pressure System

The negative pressure system on the F2513-35R4 provides a smooth flow of ink to the Print Head System. Print Quality is maintained throughout the Print without marking and the Printer is easier to maintain consistent Print results.

> Ricoh Gen4 Industrial Print Head

With available configurations from 2-6 Print Heads the Ricoh Gen4 provides value combined with versatility if you require White & Varnish Options. The Industrial design of the Print Head provides an extended lifetime using UV Inks.

Technical Specification

Printing Technology - Print Head Ricoh Gen 4 - Number of Print Heads 2-6

Productivity Performance is affected by Print Head Configuration

Express Mode- 24sqm/h

Production- 17sqm/h

Quality-13 sqm/h

Resolution & Software

Resolution- 600x2400dpi (Max)

Software- Sai Photprint

Media

Print Width- 900x600mm

Media Thickness- 340mm (Max)

Feeding & Take-Up System- Rigid media - Vacuum bed

Ink System

Ink Type- UV Curable

Ink Supply System- 1.5L - Bulk System with Automatic supply

Ink Colours- CMYK (Lc Lm White & Varnish Optional)

Ink Curing System- LED UV Curing System.

Dimensions & Weight

Machine LxWxH 3260x2080x1200mm

Operational Requirements

Connectivity- High Speed USB

Power Single Phase- 220VAC±10%, 50/60Hz; 2.4KW (Machine)

Environment Temp- 18~30°C; RH 40~60%

Positioned away from direct Sunlight - Recommended Extraction 600cfm

Warranty- 1 Year Warranty Standard

*Specifications above are subject to change without notice

YOTTA flatbed UV printers adopt industrial print heads and high-quality components, to ensure superior colour printing and strong stability. With UV LED curing systems and ECO-friendly UV-curable printing inks, YOTTA direct-to-substrate UV printers print onto a wide range of flat substrates with waterproof, anti-UV, scratch, and fade resistent characteristics. YOTTA's digital UV LED flatbed printing machines have been widely applied in different fields of printing, such as packaging, textiles, building materials. Yotta offer a wide range of options using Print Heads from Epson, Ricoh, Xaar and Kyocera. Print Heads can be configured based on customer requirements and budget for speed and number of colours required.
